Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Body Breadth
- 0.004 inch
- Pcb Contact Pattern
- RECTANGULAR
- Nominal Gerilim
- 50V
- Montaj Tipi
- Surface Mount, Right Angle
- Parça Durumu
- Active
- Total Number Of Contacts
- 22
- Seri
- FH19SC
- Pozisyon Sayısı
- 22
- Flat Flex Type
- FFC, FPC
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Insulation Resistance
- 500000000Ohm
- Pitch
- 0.020 0.50mm
- Housing Color
- Beige
- Material Flammability Rating
- UL94 V-0
- Mating Cycles
- 20
- Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- REACH Uyumluluk Kodu
- unknown
- Montaj
- Surface Mount
- Body Depth
- 0.138 inch
- Sıra Sayısı
- 1
- Cable End Type
- Tapered
- Actuator Material
- Liquid Crystal Polymer (LCP), Polyphenylene Sulfide (PPS)
- Ffc Fcb Thickness
- 0.30mm
- Contact Pattern
- RECTANGULAR
- ECCN Kodu
- EAR99
- Current Rating Amps
- 0.5A
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Resistance
- 100mOhm
- Contact Materials
- Phosphor Bronze
- Connector Type
- FFC/FPC CONNECTOR
- Contact Finish
- Gold
- HTS Kodu
- 8536.69.40.40
- Ambalaj
- Tape & Reel (TR)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gender
- Receptacle
- RoHS Durumu
- RoHS Compliant
- Actuatorcolor
- Black
- Number Of Pcb Rows
- 1
- Çalışma Sıcaklığı
- -55°C~85°C
