Adet bazlı fiyat
- 1+ adet$1.86
- 10+ adet$1.75
- 100+ adet$1.65
- 500+ adet$1.56
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -55°C~85°C
- Actuatorcolor
- Brown
- Insertion Forcemax
- ZIF N
- Connector Type
- FFC/FPC CONNECTOR
- RoHS Durumu
- RoHS Compliant
- Plating Thickness
- FLASH inch
- Kurşunsuz
- Lead Free
- Ambalaj
- Tape & Reel (TR)
- Locking Feature
- Flip Lock
- Height Above Board
- 0.035 0.88mm
- Terminal
- Solder
- Total Number Of Contacts
- 8
- Uzunluk
- 6mm
- Pitch
- 0.020 0.50mm
- Insulation Resistance
- 500000000Ohm
- Withdrawl Forcemin
- ZIF N
- Parça Durumu
- Obsolete
- Ffc Fcb Thickness
- 0.20mm
- Contact Resistance
- 100mOhm
- Reliability
- COMMERCIAL
- Flammability Rating
- UL94 V-0
- Mating Cycles
- 20
- Montaj
- Surface Mount
- Number Of Pcb Rows
- 1
- Kurşunsuz Kodu
- yes
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Radyasyon Dayanımı
- No
- Contact Finish
- Gold
- Reach Svhc
- No SVHC
- Orientation
- Right Angle
- Contact Materials
- Phosphor Bronze
- Gender
- Receptacle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reference Standard
- UL
- Akım Değeri
- 500mA
- Contact Style
- BELLOWED TYPE
- Seri
- FH19C
- Pozisyon Sayısı
- 8
- Flat Flex Type
- FFC, FPC
- Material Flammability Rating
- UL94 V-0
