Adet bazlı fiyat
- 1+ adet$0.77
- 10+ adet$0.72
- 100+ adet$0.68
- 500+ adet$0.64
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Terminal
- Solder
- Height Above Board
- 0.035 0.88mm
- Contact Style
- BELLOWED TYPE
- Reference Standard
- UL
- Akım Değeri
- 500mA
- Locking Feature
- Flip Lock
- Ambalaj
- Tape & Reel (TR)
- HTS Kodu
- 8536.69.40.51
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Type
- FFC/FPC CONNECTOR
- Contact Materials
- Phosphor Bronze
- Contact Finish
- Gold
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Number Of Pcb Rows
- 1
- Actuatorcolor
- Brown
- Çalışma Sıcaklığı
- -55°C~85°C
- Montaj
- Surface Mount
- REACH Uyumluluk Kodu
- unknown
- Body Depth
- 0.118 inch
- Reliability
- COMMERCIAL
- Flammability Rating
- UL94 V-0
- Wirecable Type
- Flat Flex
- Mating Cycles
- 20
- Fabrika Tedarik Süresi
- 10 Weeks
- Current Rating Amps
- 0.5A
- ECCN Kodu
- EAR99
- Contact Resistance
- 100mOhm
- Actuator Material
- Liquid Crystal Polymer (LCP), Polyphenylene Sulfide (PPS)
- Cable End Type
- Tapered
- Sıra Sayısı
- 1
- Contact Pattern
- RECTANGULAR
- Ffc Fcb Thickness
- 0.20mm
- Montaj Tipi
- Surface Mount, Right Angle
- Parça Durumu
- Active
- Pcb Contact Pattern
- RECTANGULAR
- Body Breadth
- 0.035 inch
- Nominal Gerilim
- 50V
- Housing Material
- Liquid Crystal Polymer (LCP)
- Insulation Resistance
- 500MOhm
