Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pozisyon Sayısı
- 40
- Contact Style
- BELLOWED TYPE
- Insulation Materials
- Nylon
- Contact Resistance
- 50mOhm
- Filter Feature
- NO
- Ambalaj
- Tape & Reel (TR)
- Gender
- Receptacle
- Çalışma Sıcaklığı
- -40°C~85°C
- Additional Feature
- TAPE AND REEL PACKAGING
- Reach Svhc
- No SVHC
- Height Above Board
- 0.079 2.00mm
- Locking Feature
- Flip Lock
- Mating Cycles
- 20
- Current Rating Amps
- 0.5A
- Actuatorcolor
- Brown
- Reliability
- COMMERCIAL
- Genişlik
- 24.1mm
- Reference Standard
- UL, CSA
- Contact Location
- Bottom
- Renk
- Beige, Brown
- Uzunluk
- 23.1mm
- Cable End Type
- Straight
- Withdrawl Forcemin
- ZIF N
- Material Flammability Rating
- UL94 V-0
- Housing Color
- Beige
- Body Breadth
- 0.079 inch
- Option
- GENERAL PURPOSE
- Voltage Rated Ac
- 50V
- Sıra Sayısı
- 1
- Ffc Fcb Thickness
- 0.30mm
- Montaj
- Surface Mount
- Max Voltage Rating Ac
- 50V
- Mixed Contacts
- NO
- Contact Materials
- Phosphor Bronze
- Terminal
- Solder
- Orientation
- Right Angle
- Lead Pitch
- 500μm
- Flammability Rating
- UL94 V-0
- Montaj Tipi
- Surface Mount, Right Angle
- Contact Finish
- Gold
