Adet bazlı fiyat
- 1+ adet$0.97
- 10+ adet$0.92
- 100+ adet$0.86
- 500+ adet$0.82
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pitch
- 0.039 1.00mm
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Iec Conformance
- NO
- Yayın Yılı
- 2010
- Özellikler
- Solder Retention, Zero Insertion Force (ZIF)
- Ul Flammability Code
- 94V-0
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- REACH Uyumluluk Kodu
- unknown
- Flat Flex Type
- FFC, FPC
- Max Current Rating
- 500mA
- Fabrika Tedarik Süresi
- 10 Weeks
- Montaj Tipi
- Surface Mount, Right Angle
- Contact Finish
- Gold
- Mil Conformance
- NO
- Actuator Material
- Polyphenylene Sulfide (PPS)
- Total Number Of Contacts
- 17
- Seri
- FH12
- Insulation Resistance
- 500MOhm
- Akım Değeri
- 500mA
- Kurşunsuz Kodu
- yes
- Wirecable Type
- Flat Flex
- Connector Type
- FFC/FPC CONNECTOR
- JESD-609 Kodu
- e4
- Din Conformance
- NO
- Montaj
- Surface Mount
- Max Voltage Rating Ac
- 50V
- Mixed Contacts
- NO
- Contact Materials
- Phosphor Bronze
- Terminal
- Solder
- Orientation
- Right Angle
- Flammability Rating
- UL94 V-0
- Housing Color
- Beige
- Option
- GENERAL PURPOSE
- Sıra Sayısı
- 1
- Ffc Fcb Thickness
- 0.30mm
- Contact Gender
- FEMALE
- Uzunluk
- 21.6mm
