Adet bazlı fiyat
- 1+ adet$0.61
- 10+ adet$0.58
- 100+ adet$0.55
- 500+ adet$0.51
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Materials
- Polyamide (PA), Nylon
- Insulation Color
- Beige
- Mating Contact Pitch
- 0.197 inch
- Number Of Positions Loaded
- All
- Montaj Tipi
- Through Hole
- Contact Materials
- Brass
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Contact Finish Mating
- Tin
- Rated Current Signal
- 7A
- Row Spacing Mating
- 0.197 (5.00mm)
- Fastening Type
- Locking Ramp
- Dielectric Withstanding Voltage
- 1500VAC V
- Pitch Mating
- 0.197 5.00mm
- Terminal
- Solder
- Number Of Pcb Rows
- 2
- Shrouding
- Shrouded - 4 Wall
- Number Of Conductors
- ONE
- Montaj
- Through Hole
- Style
- Board to Board or Cable
- ECCN Kodu
- EAR99
- Stack Height Mating
- 22.5mm
- RoHS Durumu
- RoHS Compliant
- Polarization Key
- POLARIZED HOUSING
- Insulation Resistance
- 1000000000Ohm
- Connector Type
- Header
- Durability
- 30 Cycles
- Sıra Sayısı
- 2
- Contact Type
- Male Pin
- Ambalaj
- Bulk
- Insulation Height
- 0.591 15.00mm
- Reference Standard
- UL
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Seri
- DF5
- Contact Resistance
- 30mOhm
- Fabrika Tedarik Süresi
- 10 Weeks
- Çalışma Sıcaklığı
- -35°C~85°C
- REACH Uyumluluk Kodu
- unknown
