Adet bazlı fiyat
- 1+ adet$0.77
- 10+ adet$0.73
- 100+ adet$0.69
- 500+ adet$0.65
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj
- Through Hole
- Number Of Conductors
- ONE
- Style
- Board to Cable/Wire
- Polarization Key
- POLARIZED HOUSING
- RoHS Durumu
- RoHS Compliant
- Stack Height Mating
- 22.5mm
- Connector Type
- Header
- Durability
- 30 Cycles
- Sıra Sayısı
- 1
- Contact Type
- Male Pin
- Insulation Height
- 0.591 15.00mm
- Ambalaj
- Bulk
- Seri
- DF5
- Reference Standard
- UL
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Contact Resistance
- 30mOhm
- Çalışma Sıcaklığı
- -35°C~85°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Pcb Contact Pattern
- RECTANGULAR
- REACH Uyumluluk Kodu
- unknown
- Contact Shape
- Square
- Pozisyon Sayısı
- 10
- Özellikler
- Board Guide
- Contact Length Post
- 0.138 3.50mm
- Insulation Materials
- Polyamide (PA), Nylon
- Insulation Color
- Beige
- Montaj Tipi
- Through Hole
- Kurşunsuz
- Lead Free
- Contact Materials
- Brass
- Number Of Positions Loaded
- All
- Reliability
- COMMERCIAL
- Terminal Adımı
- 5.0038mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Flammability Rating
- UL94 V-0
- Contact Finish Mating
- Tin
- Parça Durumu
- Active
- Fastening Type
- Locking Ramp
- Rated Current Signal
- 8A
- Pitch Mating
- 0.197 5.00mm
- Terminal
- Solder
