DF57-3P-1.2V(21)

Teknik Özellikler

Gender

Male

Number Of Positions Loaded

All

Contact Materials

Brass

Kurşunsuz

Lead Free

Montaj Tipi

Surface Mount

Insulation Color

Black

Insulation Materials

Liquid Crystal Polymer (LCP)

Mixed Contacts

NO

Fastening Type

Swing Lock

Parça Durumu

Obsolete

Nominal Gerilim

50V

Kurşunsuz Kodu

yes

Contact Finish Mating

Tin

Material Flammability Rating

UL94 V-0

Mil Conformance

NO

Ul Flammability Code

94V-0

Nem Hassasiyeti (MSL)

1 (Unlimited)

Reach Svhc

No SVHC

Terminal

Solder

Pitch Mating

0.047 1.20mm

Option

GENERAL PURPOSE

Shrouding

Unshrouded

Housing Material

Polymer

Filter Feature

NO

Akım Değeri

2A

RoHS Durumu

RoHS Compliant

Style

Board to Cable/Wire

Orientation

Right Angle

Montaj

Surface Mount

Iec Conformance

NO

Ambalaj

Tape & Reel (TR)

Insulation Height

0.055 1.40mm

Total Number Of Contacts

3

Contact Type

Male Blade

Sıra Sayısı

1

JESD-609 Kodu

e3

Connector Type

Header

Din Conformance

NO

Çalışma Sıcaklığı

-35°C~85°C

Seri

DF57
