DF57-2P-1.2V(21)

Teknik Özellikler

Din Conformance

NO

REACH Uyumluluk Kodu

unknown

Çalışma Sıcaklığı

-35°C~85°C

Seri

DF57

HTS Kodu

8536.69.40.40

Pozisyon Sayısı

2

Contact Shape

Rectangular

Özellikler

Solder Retention

Akım Değeri

2.5A

RoHS Durumu

RoHS Compliant

ECCN Kodu

EAR99

Style

Board to Cable/Wire

Orientation

Right Angle

Montaj

Surface Mount

Iec Conformance

NO

Insulation Height

0.055 1.40mm

Ambalaj

Tape & Reel (TR)

Total Number Of Contacts

2

Contact Type

Male Blade

Sıra Sayısı

1

JESD-609 Kodu

e3

Connector Type

Header

Reach Svhc

No SVHC

Terminal

Solder

Pitch Mating

0.047 1.20mm

Option

GENERAL PURPOSE

Shrouding

Unshrouded

Filter Feature

NO

Housing Material

Polymer

Gender

Male

Contact Materials

Brass

Kurşunsuz

Lead Free

Montaj Tipi

Surface Mount

Number Of Positions Loaded

All

Insulation Color

Black

Mixed Contacts

NO

Insulation Materials

Liquid Crystal Polymer (LCP)

Fastening Type

Swing Lock

Contact Finish Mating

Tin

Kurşunsuz Kodu

yes
