Adet bazlı fiyat
- 1+ adet$0.07
- 10+ adet$0.07
- 100+ adet$0.07
- 500+ adet$0.06
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Reliability
- COMMERCIAL
- Mil Conformance
- NO
- Connector Type
- Socket
- Rated Current Signal
- 1A
- Contact Type
- Female Socket
- Parça Durumu
- Active
- Nominal Gerilim
- 100V
- Dielectric Withstanding Voltage
- 300VAC V
- Total Number Of Contacts
- 9
- Durability
- 30 Cycles
- Fastening Type
- Latch Lock
- Kurşunsuz
- Lead Free
- Contact Resistance
- 30mOhm
- Ambalaj
- Bulk
- Din Conformance
- NO
- Gender
- Receptacle
- Pozisyon Sayısı
- 9
- Contact Finish Mating
- NOT SPECIFIED
- Sıra Sayısı
- 1
- Yayın Yılı
- 2013
- Filter Feature
- NO
- Note
- Contacts Not Included
- Seri
- DF50
- Reference Standard
- UL
- Insulation Resistance
- 500MOhm
- Depth
- 6mm
- Contact Design
- PREASSEM CONN
- Iec Conformance
- NO
- Renk
- Black
- Akım Değeri
- 1A
- Min. Çalışma Sıcaklığı
- -35°C
- Pitch
- 0.039 1.00mm
- RoHS Durumu
- RoHS Compliant
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Wire Size Max
- 28 AWG
- Genişlik
- 6.85mm
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 10.95mm
- Montaj
- Cable, Free Hanging
