Adet bazlı fiyat
- 1+ adet$0.66
- 10+ adet$0.62
- 100+ adet$0.59
- 500+ adet$0.55
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Filter Feature
- NO
- Insulation Height
- 0.278 7.06mm
- Seri
- DF50
- Shrouding
- Shrouded - 4 Wall
- Reference Standard
- UL
- Material Flammability Rating
- UL94 V-0
- Fastening Type
- Push-Pull
- Ambalaj
- Tape & Reel (TR)
- Contact Resistance
- 30mOhm
- Din Conformance
- NO
- Pozisyon Sayısı
- 7
- Contact Finish Mating
- Gold
- Sıra Sayısı
- 1
- Yayın Yılı
- 2013
- Parça Durumu
- Active
- Nominal Gerilim
- 100V
- Total Number Of Contacts
- 7
- Dielectric Withstanding Voltage
- 300VAC V
- Durability
- 30 Cycles
- Number Of Positions Loaded
- All
- Connector Type
- Header
- Mil Conformance
- NO
- Reliability
- COMMERCIAL
- HTS Kodu
- 8536.69.40.40
- Rated Current Signal
- 1A
- Contact Type
- Male Blade
- Polarization Key
- POLARIZED HOUSING
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 8 Weeks
- Housing Material
- Polymer
- Contact Gender
- Male
- ECCN Kodu
- EAR99
- Mixed Contacts
- NO
- Insulation Materials
- Polyester
- Option
- GENERAL PURPOSE
- Pcb Contact Pattern
- RECTANGULAR
- Çalışma Sıcaklığı
- -35°C~85°C
- Style
- Board to Cable/Wire
- Number Of Conductors
- ONE
- Orientation
- Straight
