Adet bazlı fiyat
- 1+ adet$0.28
- 10+ adet$0.27
- 100+ adet$0.25
- 500+ adet$0.24
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pozisyon Sayısı
- 5
- Contact Finish Mating
- Gold
- Sıra Sayısı
- 1
- Yayın Yılı
- 2013
- Fastening Type
- Push-Pull
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Tape & Reel (TR)
- Contact Resistance
- 30mOhm
- Din Conformance
- NO
- Insulation Height
- 0.278 7.06mm
- Shrouding
- Shrouded - 4 Wall
- Seri
- DF50
- Reference Standard
- UL
- Filter Feature
- NO
- Rated Current Signal
- 1A
- Contact Type
- Male Blade
- Polarization Key
- POLARIZED HOUSING
- Connector Type
- Header
- Mil Conformance
- NO
- Reliability
- COMMERCIAL
- Nominal Gerilim
- 100V
- Dielectric Withstanding Voltage
- 300VAC V
- Total Number Of Contacts
- 5
- Number Of Positions Loaded
- All
- Durability
- 30 Cycles
- Parça Durumu
- Active
- Montaj
- Surface Mount
- Montaj Tipi
- Surface Mount
- Mating Contact Pitch
- 0.039 inch
- Çalışma Sıcaklığı
- -35°C~85°C
- Style
- Board to Cable/Wire
- Number Of Conductors
- ONE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Mixed Contacts
- NO
- Insulation Materials
- Polyester
- Option
- GENERAL PURPOSE
- Pcb Contact Pattern
- RECTANGULAR
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 8 Weeks
