Adet bazlı fiyat
- 1+ adet$0.11
- 10+ adet$0.10
- 100+ adet$0.10
- 500+ adet$0.09
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Number Of Pcb Rows
- 1
- Stack Height Mating
- 7.35mm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- RoHS Durumu
- RoHS Compliant
- Pitch Mating
- 0.039 1.00mm
- Terminal
- Solder
- JESD-609 Kodu
- e3
- Iec Conformance
- NO
- Akım Değeri
- 1A
- Insulation Color
- Black
- Ul Flammability Code
- 94V-0
- Contact Materials
- Brass
- Özellikler
- Solder Retention
- Insulation Resistance
- 500MOhm
- Option
- GENERAL PURPOSE
- Insulation Materials
- Polyester
- Mixed Contacts
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Fabrika Tedarik Süresi
- 8 Weeks
- Reach Svhc
- Unknown
- Housing Material
- Polymer
- ECCN Kodu
- EAR99
- Contact Gender
- Male
- Montaj
- Surface Mount
- Montaj Tipi
- Surface Mount
- Mating Contact Pitch
- 0.039 inch
- Çalışma Sıcaklığı
- -35°C~85°C
- Style
- Board to Cable/Wire
- Number Of Conductors
- ONE
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Nominal Gerilim
- 100V
- Dielectric Withstanding Voltage
- 300VAC V
- Total Number Of Contacts
- 2
- Number Of Positions Loaded
- All
- Durability
- 30 Cycles
- Parça Durumu
- Active
- Rated Current Signal
- 1A
- Contact Type
- Male Blade
- Polarization Key
- POLARIZED HOUSING
