Adet bazlı fiyat
- 1+ adet$0.71
- 10+ adet$0.67
- 100+ adet$0.63
- 500+ adet$0.60
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Style
- Board to Cable/Wire
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Conductors
- ONE
- Çalışma Sıcaklığı
- -35°C~85°C
- Mating Contact Pitch
- 0.039 inch
- Montaj
- Surface Mount
- Montaj Tipi
- Surface Mount
- Contact Gender
- Male
- Reach Svhc
- Unknown
- Housing Material
- Polymer
- Pcb Contact Pattern
- RECTANGULAR
- Mixed Contacts
- NO
- Insulation Materials
- Polyester
- Option
- GENERAL PURPOSE
- Ul Flammability Code
- 94V-0
- Contact Materials
- Brass
- Özellikler
- Solder Retention
- Insulation Resistance
- 500MOhm
- JESD-609 Kodu
- e3
- Insulation Color
- Black
- Iec Conformance
- NO
- Akım Değeri
- 1A
- RoHS Durumu
- RoHS Compliant
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Terminal
- Solder
- Pitch Mating
- 0.039 1.00mm
- Stack Height Mating
- 7.35mm
- Number Of Pcb Rows
- 1
- Ambalaj
- Cut Tape (CT)
- Contact Resistance
- 30mOhm
- Din Conformance
- NO
- Material Flammability Rating
- UL94 V-0
- Fastening Type
- Push-Pull
- Sıra Sayısı
- 1
- Yayın Yılı
- 2013
- Pozisyon Sayısı
- 13
- Contact Finish Mating
- Gold
- Filter Feature
- NO
- Reference Standard
- UL
