Adet bazlı fiyat
- 1+ adet$0.87
- 10+ adet$0.82
- 100+ adet$0.78
- 500+ adet$0.73
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Option
- GENERAL PURPOSE
- Insulation Materials
- Polyester
- Mixed Contacts
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Housing Material
- Polymer
- Fabrika Tedarik Süresi
- 8 Weeks
- Reach Svhc
- Unknown
- Contact Gender
- Male
- Montaj Tipi
- Surface Mount
- Montaj
- Surface Mount
- Mating Contact Pitch
- 0.039 inch
- Çalışma Sıcaklığı
- -35°C~85°C
- Pcb Contact Row Spacing
- 5.588 mm
- Number Of Conductors
- ONE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Style
- Board to Cable/Wire
- Number Of Pcb Rows
- 2
- Stack Height Mating
- 7.35mm
- Pitch Mating
- 0.039 1.00mm
- Terminal
- Solder
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- RoHS Durumu
- RoHS Compliant
- Iec Conformance
- NO
- Akım Değeri
- 1A
- Insulation Color
- Black
- JESD-609 Kodu
- e3
- Contact Finish Thickness Post
- 2.00μin 0.051μm
- Insulation Resistance
- 500MOhm
- Ul Flammability Code
- 94V-0
- Contact Materials
- Brass
- Özellikler
- Solder Retention
- Seri
- DF50
- Shrouding
- Shrouded - 4 Wall
- Insulation Height
- 0.278 7.06mm
- Reference Standard
- UL
- Filter Feature
- NO
- Contact Finish Mating
- Gold
- Pozisyon Sayısı
- 50
- Yayın Yılı
- 2013
