Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Din Conformance
- NO
- Wirecable Gauge
- 28 AWG
- Ambalaj
- Bulk
- Contact Resistance
- 30mOhm
- Kurşunsuz
- Lead Free
- Bodyshell Style
- PLUG
- Yayın Yılı
- 2004
- Sıra Sayısı
- 1
- Pozisyon Sayısı
- 8
- Filter Feature
- NO
- REACH Uyumluluk Kodu
- unknown
- Additional Feature
- SOLDERED DIRECTLY TO THE BOARD
- Reference Standard
- UL
- Seri
- DF4
- Lead Pitch
- 2mm
- Contact Pattern
- RECTANGULAR
- Mil Conformance
- NO
- Connector Type
- Individual Wires
- Reliability
- COMMERCIAL
- Boardside Pitch
- 0.079 2.00mm
- Polarization Key
- HOUSING SIDE
- Rated Current Signal
- 1A
- Contact Finish
- Tin
- Parça Durumu
- Obsolete
- Number Of Positions Loaded
- All
- Body Length Or Diameter
- 0.709 inch
- Dielectric Withstanding Voltage
- 650VAC V
- Total Number Of Contacts
- 8
- Contact Style
- SQ PIN-SKT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Termination Type
- IDC
- Montaj Tipi
- Through Hole, Right Angle
- Montaj
- Through Hole
- Contact Gender
- MALE
- Housing Material
- Plastic
- Wire Gauge
- 28 AWG, Stranded
- Cable Termination
- IDC
- Operating Temperature Min
- -30°C
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
