Teknik Özellikler
- Bodyshell Style
- PLUG
- Din Conformance
- NO
- Wirecable Gauge
- 28 AWG
- Contact Resistance
- 30mOhm
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Pozisyon Sayısı
- 8
- Yayın Yılı
- 2004
- Sıra Sayısı
- 1
- REACH Uyumluluk Kodu
- unknown
- Additional Feature
- SOLDERED DIRECTLY TO THE BOARD
- Filter Feature
- NO
- Seri
- DF4
- Reference Standard
- UL
- Mil Conformance
- NO
- Connector Type
- Individual Wires
- Reliability
- COMMERCIAL
- Boardside Pitch
- 0.079 2.00mm
- Lead Pitch
- 2mm
- Contact Pattern
- RECTANGULAR
- Rated Current Signal
- 1A
- Polarization Key
- HOUSING SIDE
- Parça Durumu
- Obsolete
- Contact Finish
- Tin
- Total Number Of Contacts
- 8
- Dielectric Withstanding Voltage
- 650VAC V
- Number Of Positions Loaded
- All
- Body Length Or Diameter
- 0.709 inch
- Kurşunsuz Kodu
- yes
- Contact Style
- SQ PIN-SKT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Termination Type
- IDC
- Montaj Tipi
- Through Hole
- Montaj
- Through Hole
- Housing Material
- Plastic
- Cable Termination
- IDC
- Wire Gauge
- 28 AWG, Stranded
- Contact Gender
- MALE
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
