Teknik Özellikler
- Total Number Of Contacts
- 7
- RoHS Durumu
- RoHS Compliant
- Pitch
- 2.0066mm
- Parça Durumu
- Active
- Mounting Option1
- LOCKING
- JESD-609 Kodu
- e3
- Akım Değeri
- 3A
- Renk
- Black
- Iec Conformance
- NO
- Contact Pattern
- RECTANGULAR
- Cable Pitch
- 0.079 2.00mm
- Lead Pitch
- 2mm
- Boardside Pitch
- 0.079 2.00mm
- Özellikler
- Contacts Not Included
- Contact Materials
- Brass
- Ul Flammability Code
- 94V-0
- Mil Conformance
- NO
- Connector Type
- Housing
- Reliability
- COMMERCIAL
- Operating Temperature Min
- -30°C
- Reference Standard
- UL
- Yükseklik
- 2.8mm
- Seri
- DF4
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Voltage Rated Ac
- 250V
- Filter Feature
- NO
- Contact Gender
- Male
- Operating Temperature Max
- 85°C
- Contact Plating
- Tin
- Cable Termination
- Crimp
- Fabrika Tedarik Süresi
- 10 Weeks
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Polyamide
- Sıra Sayısı
- 1
- Yayın Yılı
- 2004
- Pozisyon Sayısı
- 7
- Uzunluk
- 14.5mm
- Contact Finish Mating
- TIN
- Montaj Tipi
- CABLE
