Teknik Özellikler
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Polarization Key
- HOUSING SIDE
- Din Conformance
- NO
- Contact Style
- SQ PIN-SKT
- Number Of Positions Loaded
- All
- Renk
- Black
- Dielectric Withstanding Voltage
- 650VAC V
- Mixed Contacts
- NO
- Yayın Yılı
- 2004
- Uzunluk
- 10mm
- Pitch
- 2.0066mm
- Housing Material
- Polyamide
- Akım Değeri
- 2A
- Pozisyon Sayısı
- 4
- Total Number Of Contacts
- 4
- Boardside Pitch
- 0.079 2.00mm
- Termination Type
- IDC
- Cable Termination
- IDC
- Lead Pitch
- 2mm
- Rated Current Signal
- 2A
- Connector Type
- Individual Wires
- Operating Temperature Max
- 85°C
- Reliability
- COMMERCIAL
- Filter Feature
- NO
- Parça Durumu
- Obsolete
- Özellikler
- Closed End
- RoHS Durumu
- RoHS Compliant
- Yükseklik
- 5.9mm
- Additional Feature
- SOLDERED DIRECTLY TO THE BOARD
- Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 1
- Option
- GENERAL PURPOSE
- Cable Pitch
- 0.079 2.00mm
- Operating Temperature Min
- -30°C
- Wirecable Gauge
- 26 AWG
- Contact Resistance
- 30mOhm
- Kurşunsuz Kodu
- yes
- REACH Uyumluluk Kodu
- unknown
- Reference Standard
- UL
