Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Through Hole
- Contact Finish
- Tin
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Through Hole
- Seri
- DF4
- Contact Gender
- MALE
- Wire Gauge
- 26 AWG, Stranded
- JESD-609 Kodu
- e3
- Mil Conformance
- NO
- Bodyshell Style
- PLUG
- REACH Uyumluluk Kodu
- unknown
- Reference Standard
- UL
- Contact Materials
- Copper
- Operating Temperature Min
- -30°C
- Contact Resistance
- 30mOhm
- Wirecable Gauge
- 26 AWG
- Cable Pitch
- 0.079 2.00mm
- Sıra Sayısı
- 1
- Option
- GENERAL PURPOSE
- Contact Pattern
- RECTANGULAR
- Additional Feature
- SOLDERED DIRECTLY TO THE BOARD
- Contact Design
- PREASSEM CONN
- RoHS Durumu
- RoHS Compliant
- Özellikler
- Closed End
- Parça Durumu
- Obsolete
- Reliability
- COMMERCIAL
- Operating Temperature Max
- 85°C
- Filter Feature
- NO
- Cable Termination
- IDC
- Termination Type
- IDC
- Connector Type
- Individual Wires
- Rated Current Signal
- 2A
- Lead Pitch
- 2mm
- Boardside Pitch
- 0.079 2.00mm
- Total Number Of Contacts
- 2
- Pozisyon Sayısı
- 2
- Housing Material
- Plastic
- Pitch
- 2.0066mm
- Ul Flammability Code
- 94V-0
