Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Obsolete
- Özellikler
- Closed End
- RoHS Durumu
- RoHS Compliant
- Contact Design
- PREASSEM CONN
- Additional Feature
- SOLDERED DIRECTLY TO THE BOARD
- Pozisyon Sayısı
- 15
- Total Number Of Contacts
- 15
- Boardside Pitch
- 0.079 2.00mm
- Lead Pitch
- 2mm
- Rated Current Signal
- 2A
- Connector Type
- Individual Wires
- Termination Type
- IDC
- Cable Termination
- IDC
- Filter Feature
- NO
- Reliability
- COMMERCIAL
- Operating Temperature Max
- 85°C
- Renk
- Black
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2004
- Mixed Contacts
- NO
- Dielectric Withstanding Voltage
- 650VAC V
- Ul Flammability Code
- 94V-0
- Pitch
- 2.0066mm
- Housing Material
- Plastic
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Polarization Key
- HOUSING SIDE
- Din Conformance
- NO
- Contact Style
- SQ PIN-SKT
- Number Of Positions Loaded
- All
- Montaj
- Through Hole
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Contact Finish
- Tin
- HTS Kodu
- 8536.69.40.40
- Montaj Tipi
- Through Hole
- Body Depth
- 0.232 inch
- JESD-609 Kodu
- e3
- Wire Gauge
- 26 AWG, Stranded
- Contact Gender
- MALE
