Adet bazlı fiyat
- 1+ adet$0.12
- 10+ adet$0.12
- 100+ adet$0.11
- 500+ adet$0.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Brass
- Reference Standard
- UL
- REACH Uyumluluk Kodu
- unknown
- Insulation Resistance
- 1000000000Ohm
- Bodyshell Style
- PLUG
- Voltage Rated Ac
- 250V
- Mil Conformance
- NO
- Contact Pattern
- RECTANGULAR
- Option
- GENERAL PURPOSE
- Sıra Sayısı
- 2
- Contact Finish Mating
- TIN
- Cable Pitch
- 0.079 2.00mm
- Contact Resistance
- 30mOhm
- Kurşunsuz Kodu
- yes
- Operating Temperature Min
- -30°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Montaj Tipi
- CABLE
- Body Depth
- 0.165 inch
- JESD-609 Kodu
- e3
- Contact Gender
- Male
- Contact Finish Termination
- TIN
- Fabrika Tedarik Süresi
- 10 Weeks
- Seri
- DF4
- Renk
- Black
- Yayın Yılı
- 2008
- Mixed Contacts
- NO
- Uzunluk
- 12.8mm
- Dielectric Withstanding Voltage
- 650VAC V
- Ul Flammability Code
- 94V-0
- Pitch
- 2.0066mm
- Housing Material
- Polyamide
- Kurşunsuz
- Lead Free
- Body Breadth
- 0.197 inch
- Ambalaj
- Bulk
- Din Conformance
- NO
- Contact Style
- SQ PIN-SKT
- Contact Plating
- Tin
- Parça Durumu
- Active
- Özellikler
- Contacts Not Included
