Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 1
- Option
- GENERAL PURPOSE
- Cable Pitch
- 0.079 2.00mm
- Operating Temperature Min
- -30°C
- Wirecable Gauge
- 28 AWG
- Contact Resistance
- 30mOhm
- Kurşunsuz Kodu
- yes
- REACH Uyumluluk Kodu
- unknown
- Contact Materials
- Copper
- Reference Standard
- UL
- Bodyshell Style
- PLUG
- Voltage Rated Ac
- 100V
- Mil Conformance
- NO
- JESD-609 Kodu
- e3
- Body Depth
- 0.232 inch
- Wire Gauge
- 28 AWG, Stranded
- Contact Gender
- Male
- Seri
- DF4
- Montaj
- Through Hole
- Contact Finish
- Tin
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Through Hole
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Contact Style
- SQ PIN-SKT
- Polarization Key
- HOUSING SIDE
- Din Conformance
- NO
- Number Of Positions Loaded
- All
- Renk
- Black
- Dielectric Withstanding Voltage
- 650VAC V
- Uzunluk
- 22mm
- Yayın Yılı
- 2004
- Mixed Contacts
- NO
- Housing Material
- Polyamide
- Pitch
- 2.0066mm
- Ul Flammability Code
- 94V-0
- Akım Değeri
- 1A
- Pozisyon Sayısı
- 10
