Adet bazlı fiyat
- 1+ adet$0.54
- 10+ adet$0.51
- 100+ adet$0.48
- 500+ adet$0.45
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Özellikler
- Solder Retention
- Parça Durumu
- Active
- Insulation Height
- 0.232 5.90mm
- RoHS Durumu
- RoHS Compliant
- Current Rating Amps
- Varies by WireGAuge
- Contact Shape
- Circular
- Montaj Tipi
- Surface Mount
- Pitch Mating
- 0.079 2.00mm
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Pozisyon Sayısı
- 14
- Insulation Color
- Beige
- Style
- Board to Board or Cable
- Shrouding
- Shrouded - 4 Wall
- Connector Type
- Header
- Çalışma Sıcaklığı
- -55°C~105°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Seri
- DF3
- Material Flammability Rating
- UL94 V-0
- Contact Materials
- Brass
- REACH Uyumluluk Kodu
- unknown
- Contact Type
- Male Pin
- Insulation Materials
- Polyamide (PA), Nylon
- Ambalaj
- Tape & Reel (TR)
- Nominal Gerilim
- 250VAC
- Fastening Type
- Push-Pull
- Stack Height Mating
- 7.5mm 7.7mm 8.4mm
- Sıra Sayısı
- 1
- Number Of Positions Loaded
- All
- Contact Finish Mating
- Gold
- Terminal
- Solder
