Adet bazlı fiyat
- 1+ adet$1.35
- 10+ adet$1.27
- 100+ adet$1.20
- 500+ adet$1.13
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- REACH Uyumluluk Kodu
- unknown
- Material Flammability Rating
- UL94 V-0
- Contact Materials
- Brass
- Contact Type
- Male Pin
- Mixed Contacts
- NO
- Insulation Materials
- Polyamide (PA), Nylon
- Mil Conformance
- NO
- Ul Flammability Code
- 94V-0
- Ambalaj
- Tape & Reel (TR)
- Nominal Gerilim
- 250VAC
- Stack Height Mating
- 7.5mm 7.7mm 8.4mm
- Din Conformance
- NO
- Sıra Sayısı
- 1
- Fastening Type
- Push-Pull
- Option
- GENERAL PURPOSE
- Contact Finish Mating
- Gold
- Number Of Positions Loaded
- All
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Terminal
- Solder
- Insulation Height
- 0.232 5.90mm
- Özellikler
- Solder Retention
- Parça Durumu
- Active
- Iec Conformance
- NO
- RoHS Durumu
- RoHS Compliant
- Pitch Mating
- 0.079 2.00mm
- Montaj Tipi
- Surface Mount
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Terminal Adımı
- 2mm
- Current Rating Amps
- Varies by WireGAuge
- Contact Shape
- Circular
- Style
- Board to Board or Cable
- Pozisyon Sayısı
- 12
- Insulation Color
- Beige
- Shrouding
- Shrouded - 4 Wall
- Total Number Of Contacts
- 12
- Çalışma Sıcaklığı
- -55°C~105°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Type
- Header
- Seri
- DF3
- Filter Feature
- NO
