Adet bazlı fiyat
- 1+ adet$0.14
- 10+ adet$0.13
- 100+ adet$0.12
- 500+ adet$0.11
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Filter Feature
- NO
- Reliability
- COMMERCIAL
- Lead Pitch
- 2mm
- Connector Type
- Header
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -55°C~105°C
- Pozisyon Sayısı
- 5
- Insertion Forcemax
- 4.3924 N
- Style
- Board to Board or Cable
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Terminal
- Press-Fit, Solder
- Number Of Positions Loaded
- All
- Mating Contact Pitch
- 0.079 inch
- Fastening Type
- Push-Pull
- Polarization Key
- GUIDE SLOT(S)
- Din Conformance
- NO
- Mounting Option1
- LOCKING
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Ul Flammability Code
- 94V-0
- Insulation Materials
- Polyamide (PA), Nylon
- Housing Material
- Plastic
- Mixed Contacts
- NO
- Yayın Yılı
- 2008
- Contact Type
- Male Pin
- Material Flammability Rating
- UL94 V-0
- Seri
- DF3
- Number Of Conductors
- ONE
- Fabrika Tedarik Süresi
- 12 Weeks
- Contact Lengthmating
- 0.122 3.10mm
- Shrouding
- Shrouded - 4 Wall
- Body Depth
- 0.283 inch
- Insulation Color
- Black
- JESD-609 Kodu
- e3
- Contact Shape
- Square
- Current Rating Amps
- 3A
- Contact Length Post
- 0.114 2.90mm
- Montaj Tipi
- Through Hole, Right Angle
- Pitch Mating
- 0.079 2.00mm
