Adet bazlı fiyat
- 1+ adet$0.35
- 10+ adet$0.33
- 100+ adet$0.31
- 500+ adet$0.29
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Sıra Sayısı
- 1
- Pcb Contact Pattern
- RECTANGULAR
- Option
- GENERAL PURPOSE
- Nominal Gerilim
- 250V
- Contact Resistance
- 30mOhm
- Kurşunsuz Kodu
- yes
- Contact Finish Mating
- Tin
- Number Of Pcb Rows
- 1
- REACH Uyumluluk Kodu
- unknown
- Reference Standard
- UL
- Contact Materials
- Brass
- Mil Conformance
- NO
- Shrouding
- Shrouded - 4 Wall
- Contact Lengthmating
- 0.122 3.10mm
- Orientation
- Straight
- Housing Color
- Black
- JESD-609 Kodu
- e3
- Number Of Conductors
- ONE
- Seri
- DF3
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Gender
- Male
- Insulation Height
- 0.197 5.00mm
- Overall Contact Length
- 0.299 7.60mm
- Montaj
- Through Hole
- Pitch Mating
- 0.079 2.00mm
- Montaj Tipi
- Through Hole
- Contact Length Post
- 0.114 2.90mm
- HTS Kodu
- 8536.69.40.40
- Contact Shape
- Square
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Polarization Key
- GUIDE SLOT(S)
- Din Conformance
- NO
- Fastening Type
- Push-Pull
- Ambalaj
- Bag
- Kurşunsuz
- Lead Free
- Terminal
- Press-Fit, Solder
- Mating Contact Pitch
- 0.079 inch
- Number Of Positions Loaded
- All
- ECCN Kodu
- EAR99
