Adet bazlı fiyat
- 1+ adet$0.11
- 10+ adet$0.11
- 100+ adet$0.10
- 500+ adet$0.09
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ul Flammability Code
- 94V-0
- Housing Material
- Plastic
- Insulation Materials
- Polyamide (PA), Nylon
- Yayın Yılı
- 2008
- Mixed Contacts
- NO
- Dielectric Withstanding Voltage
- 650VAC V
- Contact Type
- Male Pin
- ECCN Kodu
- EAR99
- Material Flammability Rating
- UL94 V-0
- Terminal
- Press-Fit, Solder
- Number Of Positions Loaded
- All
- Mating Contact Pitch
- 0.079 inch
- Fastening Type
- Push-Pull
- Din Conformance
- NO
- Polarization Key
- GUIDE SLOT(S)
- Stack Height Mating
- 5mm
- Mounting Option1
- LOCKING
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Filter Feature
- NO
- Reliability
- COMMERCIAL
- Lead Pitch
- 2mm
- Connector Type
- Header
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -55°C~105°C
- Pozisyon Sayısı
- 10
- Insertion Forcemax
- 4.3924 N
- Style
- Board to Board or Cable
- Voltage Rated Ac
- 30V
- Mil Conformance
- NO
- Insulation Resistance
- 1GOhm
- Number Of Pcb Rows
- 1
- Contact Materials
- Brass
- Reference Standard
- UL
- REACH Uyumluluk Kodu
- unknown
- Contact Resistance
- 30mOhm
- Kurşunsuz Kodu
- yes
