Adet bazlı fiyat
- 1+ adet$0.47
- 10+ adet$0.44
- 100+ adet$0.42
- 500+ adet$0.39
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Number Of Conductors
- ONE
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Insertion Forcemax
- 4.3924 N
- Shrouding
- Shrouded - 4 Wall
- Rated Current Signal
- 3A
- Contact Materials
- Brass
- Depth
- 5mm
- Reliability
- COMMERCIAL
- Ul Flammability Code
- 94V-0
- Filter Feature
- NO
- Reference Standard
- UL, CSA
- Dielectric Withstanding Voltage
- 650VAC V
- Parça Durumu
- Active
- Max Current Rating
- 3A
- Contact Lengthmating
- 0.122 3.10mm
- Pcb Contact Pattern
- RECTANGULAR
- Çalışma Sıcaklığı
- -55°C~105°C
- Mil Conformance
- NO
- Withdrawl Forcemin
- .3058 N
- Radyasyon Dayanımı
- No
- Lead Pitch
- 2mm
- HTS Kodu
- 8536.69.40.40
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Through Hole
- Insulation Materials
- Polyamide (PA), Nylon
- Contact Shape
- Square
- Fastening Type
- Push-Pull
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Ac
- 100V
- Ambalaj
- Bulk
- Iec Conformance
- NO
- Sıra Sayısı
- 1
- Number Of Positions Loaded
- All
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide
- Contact Finish Mating
- Gold
- Housing Color
- Black
- Nominal Gerilim
- 100V
- Overall Contact Length
- 0.299 7.60mm
- Yükseklik
- 5mm
