Adet bazlı fiyat
- 1+ adet$1.31
- 10+ adet$1.23
- 100+ adet$1.16
- 500+ adet$1.10
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Cable Termination
- Solder
- Body Length Or Diameter
- 0.969 inch
- Reach Svhc
- No SVHC
- Termination Type
- SURFACE MOUNT
- Connector Type
- Plug
- Reliability
- COMMERCIAL
- Operating Temperature Max
- 85°C
- Filter Feature
- NO
- Pozisyon Sayısı
- 50
- Total Number Of Contacts
- 50
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Ambalaj
- Tape & Reel (TR)
- Din Conformance
- NO
- Fastening Type
- Latch Holder
- Contact Type
- Outer Shroud Contact
- Mixed Contacts
- NO
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Pitch
- 0.016 0.40mm
- Durability
- 30 Cycles
- Ul Flammability Code
- 94V-0
- ECCN Kodu
- EAR99
- Renk
- Natural
- Wire Type
- Discrete
- Fabrika Tedarik Süresi
- 10 Weeks
- Number Of Conductors
- ONE
- Wire Gauge Max
- 46 AWG
- Seri
- DF36
- JESD-609 Kodu
- e4
- Body Depth
- 0.059 inch
- Wire Gauge
- 42-46 AWG
- Wire Gauge Min
- 42 AWG
- Contact Finish
- Gold
- Iec Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gender
- Male
- Montaj Tipi
- Free Hanging (In-Line)
- HTS Kodu
- 8536.69.40.40
- Montaj
- Free Hanging
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
