DF3-4S-2DSA(25)

Teknik Özellikler

Genişlik

4.58mm

Akım Değeri

3A

Parça Durumu

Active

Terminal

Solder

Stack Height Mating

6.6mm 7.5mm

ECCN Kodu

EAR99

Connector Type

Receptacle

Fabrika Tedarik Süresi

12 Weeks

Çalışma Sıcaklığı

-30°C~85°C

Pozisyon Sayısı

4

Lead Pitch

2mm

Yayın Yılı

2004

Kurşunsuz

Lead Free

Montaj Tipi

Through Hole

Insulation Materials

Polyamide (PA), Nylon

Seri

DF3

Contact Shape

Square

Fastening Type

Friction Lock

Nem Hassasiyeti (MSL)

1 (Unlimited)

Ambalaj

Tube

Pitch Mating

0.079 2.00mm

Sıra Sayısı

1

Material Flammability Rating

UL94 V-0

Number Of Positions Loaded

All

Housing Material

Plastic

Contact Length Post

0.118 3.00mm

Contact Finish Mating

Tin

Nominal Gerilim

30VAC

Housing Color

Black

Yükseklik

5.9mm

Contact Materials

Phosphor Bronze

Style

Board to Board or Cable

Contact Type

Female Socket

RoHS Durumu

RoHS Compliant

Uzunluk

10mm

Contact Gender

Female

Insulation Height

0.232 5.90mm

Montaj

Through Hole

Contact Finish Thickness Mating

78.7μin 2.00μm

Orientation

Straight
