Adet bazlı fiyat
- 1+ adet$0.23
- 10+ adet$0.22
- 100+ adet$0.21
- 500+ adet$0.20
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 10mm
- Polarization Key
- HOUSING SIDE
- Contact Resistance
- 30mOhm
- Style
- Board to Board or Cable
- Contact Type
- Male Pin
- Yükseklik
- 5mm
- Overall Contact Length
- 0.299 7.60mm
- Durability
- 50 Cycles
- Kurşunsuz Kodu
- yes
- Housing Color
- Black
- Nominal Gerilim
- 100V
- Option
- GENERAL PURPOSE
- Number Of Pcb Rows
- 1
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Orientation
- Straight
- Reach Svhc
- No SVHC
- Montaj
- Through Hole
- Insulation Height
- 0.197 5.00mm
- Contact Gender
- Male
- Din Conformance
- NO
- Pozisyon Sayısı
- 4
- Mixed Contacts
- NO
- ECCN Kodu
- EAR99
- Terminal
- Press-Fit, Solder
- Connector Type
- Header
- Fabrika Tedarik Süresi
- 12 Weeks
- JESD-609 Kodu
- e4
- Akım Değeri
- 3A
- Contact Length Post
- 0.114 2.90mm
- Pitch Mating
- 0.079 2.00mm
- Seri
- DF3
- Yayın Yılı
- 2008
- Depth
- 5mm
- Shrouding
- Shrouded - 4 Wall
- Contact Materials
- Brass
- Rated Current Signal
- 3A
- Number Of Conductors
- ONE
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Reference Standard
- UL, CSA
