Adet bazlı fiyat
- 1+ adet$0.23
- 10+ adet$0.22
- 100+ adet$0.21
- 500+ adet$0.20
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pozisyon Sayısı
- 8
- Note
- Contacts Not Included
- Contact Termination
- Crimp
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Type
- Receptacle
- ECCN Kodu
- EAR99
- Insulation Resistance
- 1000000000Ohm
- Parça Durumu
- Active
- Termination Type
- WIRE
- Dielectric Withstanding Voltage
- 1500VAC V
- Contact Finish Mating
- SN
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Fastening Type
- Latch Lock
- Pitch
- 0.130 3.30mm
- Sıra Sayısı
- 2
- Operating Temperature Min
- -35°C
- Seri
- EnerBee™ DF33C
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Materials
- POLYBUTYLENE TEREPHTHALATE
- Contact Resistance
- 10mOhm
- RoHS Durumu
- RoHS Compliant
- Contact Type
- Female Socket
- Rated Current Signal
- 5A
- Durability
- 30 Cycles
- Mounting Option1
- LOCKING
- Contact Materials
- COPPER ALLOY
- Row Spacing
- 0.228 (5.80mm)
- Reference Standard
- UL
- Renk
- White
- Total Number Of Contacts
- 8
- Reach Svhc
- Unknown
- Reliability
- COMMERCIAL
