DF33-5S-3.3C

Teknik Özellikler

Uzunluk

17.7mm

RoHS Durumu

RoHS Compliant

Depth

14mm

Contact Type

Female Socket

Kurşunsuz Kodu

yes

Contact Materials

COPPER ALLOY

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Gender

Female

Option

GENERAL PURPOSE

REACH Uyumluluk Kodu

unknown

Total Number Of Contacts

5

Ul Flammability Code

94V-0

Renk

Natural

Additional Feature

COMPATIBLE CONTACTS: DF33A-2022SCF; DF33A-2022SC

Filter Feature

NO

Orientation

Straight

Montaj

Cable, Free Hanging

Note

Contacts Not Included

Din Conformance

NO

Mil Conformance

NO

Contact Termination

Crimp

Pozisyon Sayısı

5

Mixed Contacts

NO

ECCN Kodu

EAR99

Fabrika Tedarik Süresi

10 Weeks

Connector Type

Receptacle

JESD-609 Kodu

e3

Genişlik

7.4mm

Parça Durumu

Active

Housing Material

Polyamide

Contact Finish Mating

TIN

Nem Hassasiyeti (MSL)

1 (Unlimited)

Iec Conformance

NO

Ambalaj

Bulk

Fastening Type

Latch Lock

Pitch

0.130 3.30mm

Sıra Sayısı

1

Montaj Tipi

Free Hanging (In-Line)

Seri

EnerBee™ DF33
