Adet bazlı fiyat
- 1+ adet$0.59
- 10+ adet$0.56
- 100+ adet$0.52
- 500+ adet$0.50
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Dielectric Withstanding Voltage
- 650VAC V
- Parça Durumu
- Active
- Contact Lengthmating
- 0.122 3.10mm
- Pcb Contact Pattern
- RECTANGULAR
- Çalışma Sıcaklığı
- -55°C~105°C
- Mil Conformance
- NO
- Lead Pitch
- 2mm
- Withdrawl Forcemin
- .3058 N
- HTS Kodu
- 8536.69.40.40
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Through Hole, Right Angle
- Insulation Materials
- Polyamide (PA), Nylon
- Iec Conformance
- NO
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Type
- Push-Pull
- Contact Shape
- Square
- Sıra Sayısı
- 1
- Number Of Positions Loaded
- All
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Plastic
- Contact Finish Mating
- Gold
- Number Of Conductors
- ONE
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Insertion Forcemax
- 4.3924 N
- Shrouding
- Shrouded - 4 Wall
- Rated Current Signal
- 3A
- Contact Materials
- Brass
- Mating Contact Pitch
- 0.079 inch
- Reliability
- COMMERCIAL
- Ul Flammability Code
- 94V-0
- Filter Feature
- NO
- Reference Standard
- UL, CSA
- Akım Değeri
- 3A
- JESD-609 Kodu
- e4
- Terminal
- Press-Fit, Solder
- ECCN Kodu
- EAR99
- Connector Type
- Header
- Fabrika Tedarik Süresi
- 10 Weeks
- Mixed Contacts
- NO
