Teknik Özellikler
- Filter Feature
- NO
- Ul Flammability Code
- 94V-0
- Reference Standard
- UL, CSA
- Mating Contact Pitch
- 0.079 inch
- Reliability
- COMMERCIAL
- Insertion Forcemax
- 4.3924 N
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Number Of Conductors
- ONE
- Contact Materials
- Brass
- Rated Current Signal
- 3A
- Shrouding
- Shrouded - 4 Wall
- Sıra Sayısı
- 1
- Iec Conformance
- NO
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fastening Type
- Push-Pull
- Contact Shape
- Square
- Contact Finish Mating
- Gold
- Housing Material
- Polyamide
- Number Of Positions Loaded
- All
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- HTS Kodu
- 8536.69.40.40
- Insulation Materials
- Polyamide (PA), Nylon
- Montaj Tipi
- Through Hole, Right Angle
- Çalışma Sıcaklığı
- -55°C~105°C
- Withdrawl Forcemin
- .3058 N
- Lead Pitch
- 2mm
- Mil Conformance
- NO
- Contact Lengthmating
- 0.122 3.10mm
- Parça Durumu
- Active
- Dielectric Withstanding Voltage
- 650VAC V
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Number Of Pcb Rows
- 1
- REACH Uyumluluk Kodu
- unknown
- Option
- GENERAL PURPOSE
- Contact Gender
- Male
- Insulation Height
- 0.197 5.00mm
- Montaj
- Through Hole
