Adet bazlı fiyat
- 1+ adet$1.14
- 10+ adet$1.07
- 100+ adet$1.01
- 500+ adet$0.95
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Row Spacing Mating
- 0.039 (1.00mm)
- Material Flammability Rating
- UL94 V-0
- Max Current Rating
- 1A
- Seri
- DF20
- Contact Finish Mating
- Gold
- Insulation Height
- 0.181 4.60mm
- Ul Flammability Code
- 94V-0
- Ambalaj
- Tube
- Mil Conformance
- NO
- Housing Material
- Polyamide
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Orientation
- Straight
- Pitch Mating
- 0.039 1.00mm
- HTS Kodu
- 8536.69.40.40
- Contact Gender
- Male
- Pozisyon Sayısı
- 10
- Contact Shape
- Square
- Mixed Contacts
- NO
- Din Conformance
- NO
- Uzunluk
- 7.3mm
- Çalışma Sıcaklığı
- -35°C~85°C
- Radyasyon Dayanımı
- No
- Insulation Resistance
- 500MOhm
- Reach Svhc
- No SVHC
- Contact Type
- Male Pin
- ECCN Kodu
- EAR99
- Stack Height Mating
- 5.8mm
- Style
- Board to Cable/Wire
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Type
- Header
- Total Number Of Contacts
- 10
- Insulation Materials
- Polyamide (PA), Nylon
- Renk
- Beige
- Parça Durumu
- Active
- Insulation
- Insulated
- Yayın Yılı
- 2002
- Özellikler
- Solder Retention
- Insulation Color
- Natural
- Fastening Type
- Push-Pull
- Number Of Positions Loaded
- All
