Adet bazlı fiyat
- 1+ adet$0.97
- 10+ adet$0.92
- 100+ adet$0.87
- 500+ adet$0.82
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 10 Weeks
- Connector Type
- Header
- Contact Type
- Male Pin
- Stack Height Mating
- 14.3mm 15.8mm 19.8mm
- Style
- Board to Cable/Wire
- Current Rating Amps
- 3A
- Insulation Materials
- Polyamide (PA), Nylon
- Montaj
- Through Hole
- Contact Materials
- Brass
- Sıra Sayısı
- 1
- Çalışma Sıcaklığı
- -35°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Through Hole
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Shrouding
- Shrouded - 4 Wall
- Pozisyon Sayısı
- 5
- Contact Shape
- Square
- Pitch Mating
- 0.098 2.50mm
- Contact Lengthmating
- 0.177 4.50mm
- REACH Uyumluluk Kodu
- unknown
- Insulation Color
- Natural
- Material Flammability Rating
- UL94 V-0
- Contact Length Post
- 0.142 3.60mm
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Number Of Positions Loaded
- All
- Fastening Type
- Latch Holder
- Seri
- DF1E
- Contact Finish Mating
- Tin
- Insulation Height
- 0.425 10.80mm
