DF1EA-9EP-2.5C

Teknik Özellikler

Contact Termination

Crimp

Ambalaj

Bulk

Contact Finish Mating

NOT SPECIFIED

Seri

DF1E

Fastening Type

Latch Holder

Durability

30 Cycles

REACH Uyumluluk Kodu

unknown

Parça Durumu

Active

Operating Temperature Max

85°C

Body Depth

0.74 inch

Renk

White

Pozisyon Sayısı

9

Contact Resistance

30mOhm

Filter Feature

NO

Kurşunsuz

Lead Free

Option

GENERAL PURPOSE

Housing Material

Polyamide

Mil Conformance

NO

Iec Conformance

NO

Nem Hassasiyeti (MSL)

1 (Unlimited)

Montaj Tipi

Free Hanging (In-Line)

Reference Standard

UL

RoHS Durumu

RoHS Compliant

Voltage Rated Ac

250V

Body Breadth

0.354 inch

Note

Contacts Not Included

Polarization Key

POLARIZED HOUSING

Uzunluk

25.5mm

Akım Değeri

3A

Din Conformance

NO

Reliability

COMMERCIAL

Kurşunsuz Kodu

yes

Mixed Contacts

NO

Contact Materials

NOT SPECIFIED

Montaj

Free Hanging

Dielectric Withstanding Voltage

650VAC V

Sıra Sayısı

1

Total Number Of Contacts

9

Pitch

0.098 2.50mm

Operating Temperature Min

-35°C
