Adet bazlı fiyat
- 1+ adet$0.87
- 10+ adet$0.82
- 100+ adet$0.78
- 500+ adet$0.73
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Current Rating Amps
- 3A
- Style
- Board to Cable/Wire
- ECCN Kodu
- EAR99
- Contact Type
- Male Pin
- Mating Contact Pitch
- 0.098 inch
- Connector Type
- Header
- Fabrika Tedarik Süresi
- 10 Weeks
- Sıra Sayısı
- 1
- Contact Materials
- Brass
- Number Of Conductors
- ONE
- Insulation Materials
- Polyamide (PA), Nylon
- Montaj
- Through Hole
- Reliability
- COMMERCIAL
- Çalışma Sıcaklığı
- -35°C~85°C
- Terminal Adımı
- 2.4892mm
- Montaj Tipi
- Through Hole, Right Angle
- RoHS Durumu
- RoHS Compliant
- Reference Standard
- UL
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Number Of Pcb Rows
- 1
- HTS Kodu
- 8536.69.40.40
- Pitch Mating
- 0.098 2.50mm
- Contact Lengthmating
- 0.177 4.50mm
- Contact Shape
- Square
- Pozisyon Sayısı
- 12
- Shrouding
- Shrouded - 4 Wall
- Contact Resistance
- 30mOhm
- Contact Length Post
- 0.114 2.90mm
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Insulation Color
- Natural
- REACH Uyumluluk Kodu
- unknown
- Contact Finish Mating
- Tin
- Insulation Height
- 0.315 8.00mm
- Seri
- DF1E
- Fastening Type
- Latch Holder
- Ambalaj
- Bulk
