DF1E-10EP-2.5C

Teknik Özellikler

Dielectric Withstanding Voltage

650VAC V

Montaj

Panel, Snap in

Contact Materials

NOT SPECIFIED

Sıra Sayısı

1

Nem Hassasiyeti (MSL)

1 (Unlimited)

Body Breadth

0.35 inch

RoHS Durumu

RoHS Compliant

Montaj Tipi

Panel Mount, Snap-In

Kurşunsuz Kodu

yes

Akım Değeri

3A

Contact Resistance

30mOhm

Option

GENERAL PURPOSE

Kurşunsuz

Lead Free

Filter Feature

NO

Iec Conformance

NO

Fastening Type

Latch Holder

REACH Uyumluluk Kodu

unknown

Renk

White

Nominal Gerilim

250V

Parça Durumu

Active

Operating Temperature Min

-35°C

Pitch

0.098 2.50mm

Total Number Of Contacts

10

Rated Current Signal

3A

Fabrika Tedarik Süresi

10 Weeks

Yükseklik

9mm

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Connector Type

Plug

Contact Type

Male Pin

ECCN Kodu

EAR99

Polarization Key

POLARIZED HOUSING

Note

Contacts Not Included

Voltage Rated Ac

250V

Reference Standard

UL

Uzunluk

35mm

Mixed Contacts

NO

Reliability

COMMERCIAL

Din Conformance

NO

Contact Design

PREASSEM CONN

Pozisyon Sayısı

10
