Adet bazlı fiyat
- 1+ adet$0.76
- 10+ adet$0.71
- 100+ adet$0.67
- 500+ adet$0.64
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Style
- Board to Cable/Wire
- Contact Materials
- Brass
- Akım Değeri
- 3A
- Number Of Pcb Rows
- 2
- Yükseklik
- 8.6mm
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 150V
- Connector Type
- Header
- Polarization Key
- POLARIZED HOUSING
- Contact Gender
- Male
- JESD-609 Kodu
- e3/e4
- Shrouding
- Shrouded - 4 Wall
- Row Spacing Mating
- 0.098 (2.50mm)
- Housing Color
- White
- Rated Current Signal
- 3A
- REACH Uyumluluk Kodu
- unknown
- Parça Durumu
- Active
- Insulation Materials
- Polyamide (PA), Nylon
- Contact Shape
- Square
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Çalışma Sıcaklığı
- -35°C~85°C
- Sıra Sayısı
- 2
- Uzunluk
- 32.5mm
- Ambalaj
- Bulk
- Contact Type
- Male Pin
- Housing Material
- Polyamide
- Lead Pitch
- 2.5mm
- Kurşunsuz Kodu
- yes
- Pcb Contact Pattern
- RECTANGULAR
- Insulation Height
- 0.339 8.61mm
- Durability
- 30 Cycles
- Insulation Resistance
- 1000000000Ohm
- Number Of Positions Loaded
- All
- Contact Resistance
- 30mOhm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Filter Feature
- NO
- Ul Flammability Code
- 94V-0
- Option
- GENERAL PURPOSE
- Terminal
- Solder
- Din Conformance
- NO
