Adet bazlı fiyat
- 1+ adet$0.61
- 10+ adet$0.57
- 100+ adet$0.54
- 500+ adet$0.51
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Özellikler
- Feed Through
- Total Number Of Contacts
- 3
- Operating Temperature Max
- 85°C
- Filter Feature
- NO
- Mounting Option1
- LOCKING
- Withdrawl Forcemin
- .556 N
- Reliability
- COMMERCIAL
- Iec Conformance
- NO
- Ul Flammability Code
- 94V-0
- Montaj Tipi
- Free Hanging (In-Line)
- JESD-609 Kodu
- e3
- Renk
- Brown
- Option
- GENERAL PURPOSE
- Insulation Resistance
- 1GOhm
- Connector Type
- Socket
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 250V
- Din Conformance
- NO
- Sıra Sayısı
- 1
- Seri
- DF1
- Additional Feature
- LOW PROFILE
- Housing Material
- Polyamide
- Pitch
- 0.098 2.50mm
- Cable Termination
- IDC
- Dielectric Withstanding Voltage
- 650VAC V
- ECCN Kodu
- EAR99
- Mil Conformance
- NO
- REACH Uyumluluk Kodu
- unknown
- Contact Finish
- Tin
- Termination Type
- IDC
- RoHS Durumu
- RoHS Compliant
- Rated Current Signal
- 2A
- Pozisyon Sayısı
- 3
- Ambalaj
- Bulk
- Mixed Contacts
- NO
- Wire Type
- Discrete
- Contact Type
- Female Socket
- Fabrika Tedarik Süresi
- 10 Weeks
- Reference Standard
- UL
- Contact Gender
- Female
