Adet bazlı fiyat
- 1+ adet$2.39
- 10+ adet$2.25
- 100+ adet$2.12
- 500+ adet$2.00
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Shape
- Square
- Filter Feature
- NO
- Insulation Materials
- Polyamide (PA), Nylon
- Mating Contact Pitch
- 0.049 inch
- Montaj Tipi
- Surface Mount, Right Angle
- Number Of Conductors
- ONE
- Style
- Board to Cable/Wire
- Insulation Color
- Beige
- Mil Conformance
- NO
- Durability
- 50 Cycles
- Mixed Contacts
- NO
- Reliability
- COMMERCIAL
- Contact Type
- Male Pin
- Pozisyon Sayısı
- 14
- ECCN Kodu
- EAR99
- JESD-609 Kodu
- e4
- Material Flammability Rating
- UL94 V-0
- Uzunluk
- 22.15mm
- Özellikler
- Solder Retention
- Fastening Type
- Detent Lock
- Ambalaj
- Tape & Reel (TR)
- Seri
- DF13
- Contact Finish Thickness Mating
- 8.00μin 0.203μm
- Insertion Forcemax
- 3.0024 N
- Orientation
- Right Angle
- Max Voltage Rating Ac
- 150V
- Shrouding
- Shrouded - 4 Wall
- Pitch Mating
- 0.049 1.25mm
- Number Of Positions Loaded
- All
- Contact Resistance
- 30mOhm
- Connector Type
- Header
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Iec Conformance
- NO
- Terminal
- Solder
- Total Number Of Contacts
- 14
- Çalışma Sıcaklığı
- -35°C~85°C
- Insulation Height
- 0.142 3.60mm
- Depth
- 5mm
