DF12(4.0)-50DP-0.5V(86)

Teknik Özellikler

JESD-609 Kodu

e4

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Ul Flammability Code

94V-0

Stack Height Mating

4mm

Pitch

0.020 0.50mm

Total Number Of Contacts

50

Filter Feature

NO

Iec Conformance

NO

Lead Pitch

500μm

Seri

DF12

RoHS Durumu

RoHS Compliant

Housing Material

Plastic

Akım Değeri

300mA

Nem Hassasiyeti (MSL)

1 (Unlimited)

Contact Finish Thickness

8.00μin 0.203μm

HTS Kodu

8536.69.40.40

Pozisyon Sayısı

50

Mil Conformance

NO

Montaj Tipi

Surface Mount

Connector Type

Header, Outer Shroud Contacts

Fabrika Tedarik Süresi

12 Weeks

Din Conformance

NO

Ambalaj

Tape & Reel (TR)

Mixed Contacts

NO

Height Above Board

0.130 3.30mm

Parça Durumu

Active

Voltage Rated Ac

50V

ECCN Kodu

EAR99

Option

GENERAL PURPOSE

Contact Resistance

50mOhm

Housing Color

Beige

Insulation Resistance

500MOhm

Gender

Male

Özellikler

Board Guide, Solder Retention

Genişlik

15.5mm

Kurşunsuz

Lead Free

Contact Finish

Gold

Contact Materials

BRASS

Sıra Sayısı

2
