DF12(3.0)-40DP-0.5V(86)

Teknik Özellikler

Montaj Tipi

Surface Mount

Mil Conformance

NO

Pozisyon Sayısı

40

Contact Finish Thickness

8.00μin 0.203μm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Akım Değeri

300mA

Seri

DF12

RoHS Durumu

RoHS Compliant

Filter Feature

NO

Iec Conformance

NO

Total Number Of Contacts

40

Pitch

0.020 0.50mm

Stack Height Mating

3mm

Ul Flammability Code

94V-0

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Genişlik

13mm

Özellikler

Board Guide, Solder Retention

Contact Materials

BRASS

Sıra Sayısı

2

Contact Finish

Gold

Insulation Resistance

500MOhm

Contact Resistance

50mOhm

Option

GENERAL PURPOSE

Contact Gender

MALE

Voltage Rated Ac

50V

Parça Durumu

Active

Height Above Board

0.091 2.30mm

ECCN Kodu

EAR99

Ambalaj

Tape & Reel (TR)

Mixed Contacts

NO

Din Conformance

NO

Fabrika Tedarik Süresi

10 Weeks

REACH Uyumluluk Kodu

unknown

Connector Type

Header, Outer Shroud Contacts
