DF12(3.0)-14DS-0.5V(86)

Teknik Özellikler

Reference Standard

UL

Depth

3.6mm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Durability

50 Cycles

Akım Değeri

300mA

Mil Conformance

NO

Montaj Tipi

Surface Mount

Max Current Rating

300mA

Number Of Pcb Rows

2

Pozisyon Sayısı

14

Total Number Of Contacts

14

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Iec Conformance

NO

Filter Feature

NO

Contact Resistance

50mOhm

Orientation

Straight

Kurşunsuz

Lead Free

Uzunluk

6.5mm

Fabrika Tedarik Süresi

10 Weeks

Din Conformance

NO

Contact Pattern

RECTANGULAR

Mixed Contacts

NO

Terminal

SMD/SMT

Ambalaj

Tape & Reel (TR)

Nominal Gerilim

50V

ECCN Kodu

EAR99

Height Above Board

0.087 2.20mm

RoHS Durumu

RoHS Compliant

Seri

DF12

Housing Material

Polyamide

Contact Finish Thickness

8.00μin 0.203μm

HTS Kodu

8536.69.40.40

Montaj

Surface Mount

Pitch

0.020 0.50mm

JESD-609 Kodu

e4

Dielectric Withstanding Voltage

150VAC V

Ul Flammability Code

94V-0

Number Of Conductors

ONE

Reliability

COMMERCIAL

Rated Current Signal

0.3A
