Adet bazlı fiyat
- 1+ adet$0.77
- 10+ adet$0.72
- 100+ adet$0.68
- 500+ adet$0.64
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Gender
- Male
- Contact Finish Mating
- Tin
- Özellikler
- Board Guide, Solder Retention
- Sıra Sayısı
- 2
- Contact Materials
- Brass
- Housing Color
- Beige
- Insulation Resistance
- 1000000000Ohm
- Parça Durumu
- Active
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Fastening Type
- Detent Lock
- Option
- GENERAL PURPOSE
- Row Spacing Mating
- 0.079 (2.00mm)
- Connector Type
- Header
- Plating Thickness
- 39μin
- Material Flammability Rating
- UL94 V-0
- Pcb Contact Row Spacing
- 8.3058 mm
- Housing Material
- Polyamide
- Insulation Height
- 0.283 7.19mm
- Lead Pitch
- 2mm
- Seri
- DF11
- RoHS Durumu
- RoHS Compliant
- Radyasyon Dayanımı
- No
- Rated Current Signal
- 2A
- Reliability
- COMMERCIAL
- Number Of Conductors
- ONE
- Ul Flammability Code
- 94V-0
- JESD-609 Kodu
- e3
- Pitch Mating
- 0.079 2.00mm
- Shrouding
- Shrouded - 4 Wall
- Montaj
- Surface Mount
- Uzunluk
- 13.5mm
- Çalışma Sıcaklığı
- -30°C~85°C
- Orientation
- Straight
- Kurşunsuz
- Lead Free
- Contact Shape
- Circular
- Contact Resistance
- 30mOhm
- Kurşunsuz Kodu
- yes
- Number Of Positions Loaded
- All
- Nominal Gerilim
- 250V
