Adet bazlı fiyat
- 1+ adet$1.22
- 10+ adet$1.16
- 100+ adet$1.09
- 500+ adet$1.03
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Resistance
- 1GOhm
- Sıra Sayısı
- 2
- Contact Materials
- Phosphor Bronze
- Özellikler
- Pick and Place, Solder Retention
- Contact Finish Mating
- Tin
- Connector Type
- Receptacle
- Material Flammability Rating
- UL94 V-0
- REACH Uyumluluk Kodu
- unknown
- Fastening Type
- Friction Lock
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Voltage Rated Ac
- 30V
- Parça Durumu
- Active
- Contact Gender
- Female
- Row Spacing Mating
- 0.079 (2.00mm)
- RoHS Durumu
- RoHS Compliant
- Seri
- DF11
- Lead Pitch
- 2mm
- Insulation Height
- 0.234 5.95mm
- Housing Material
- Polyamide
- Pitch Mating
- 0.079 2.00mm
- Montaj
- Surface Mount
- Reach Svhc
- No SVHC
- Flammability Rating
- UL94 V-0
- Applications
- General Purpose
- Contact Resistance
- 30mOhm
- Contact Shape
- Square
- Uzunluk
- 15.5mm
- Orientation
- Straight
- Çalışma Sıcaklığı
- -30°C~85°C
- Renk
- Black
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Ambalaj
- Tape & Reel (TR)
- Terminal
- Solder
- Nominal Gerilim
- 250V
- ECCN Kodu
- EAR99
- Number Of Positions Loaded
- All
- Akım Değeri
- 1A
- Contact Type
- Female Socket
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
