Adet bazlı fiyat
- 1+ adet$1.66
- 10+ adet$1.56
- 100+ adet$1.47
- 500+ adet$1.39
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Özellikler
- Pick and Place, Solder Retention
- Contact Materials
- Phosphor Bronze
- Sıra Sayısı
- 2
- Contact Finish Mating
- Tin
- Insulation Resistance
- 1000000000Ohm
- Row Spacing Mating
- 0.079 (2.00mm)
- Contact Gender
- Female
- Contact Finish Thickness Mating
- 39.4μin 1.00μm
- Fastening Type
- Friction Lock
- Parça Durumu
- Active
- Pcb Contact Pattern
- RECTANGULAR
- Connector Type
- Receptacle
- Material Flammability Rating
- UL94 V-0
- REACH Uyumluluk Kodu
- unknown
- HTS Kodu
- 8536.69.40.40
- Withdrawl Forcemin
- .3058 N
- Insulation Height
- 0.234 5.95mm
- Seri
- DF11
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyamide
- Number Of Conductors
- ONE
- Rated Current Signal
- 2A
- Reliability
- COMMERCIAL
- Applications
- General Purpose
- Montaj
- Surface Mount
- Dielectric Withstanding Voltage
- 650VAC V
- Pitch Mating
- 0.079 2.00mm
- Orientation
- Straight
- Renk
- Beige, Black
- Çalışma Sıcaklığı
- -30°C~85°C
- Contact Resistance
- 30mOhm
- Contact Shape
- Square
- Terminal
- Solder
- Ambalaj
- Tape & Reel (TR)
- Number Of Positions Loaded
- All
- Nominal Gerilim
- 250V
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Polarization Key
- HOUSING SIDE
